Features:
- Support HDMI 2.0 ,HDCP2.2
- Support HDR (for SFX911-4, SFX911-8)
- Support 3D video format
- Support CEC (only output1)
- Support High Resolution up to 3840 X 2160/60HZ
- Support the Max Baud Rate of 6G and TMDS clock can be up to 600 MHz
- Support 8/10/12 bit deep color
- Support AWG26 HDMI standard cable:
- when the Resolution is 1080p and below, input up to 8 meters, output to 8 meters. When the resolution is 4K, input up to 8 meters, output up to 8 meters. Support single HDMI source, accessing to multiple HDMI sinks, the source can be DVD player, A/V receiver, set top box and etc.
- Built-in IR extension function.( it can work with our HDMI 2.0 repeater which has IR-RX to receive the IR command to remote control the source)
- Support Serial Port Online Upgrade
- Support EDID management
- 5V/2A Power Adapter
Specifications:
-
Brand: ArgoX
-
Model(s): SFX911-2 / SFX911-4 / SFX911-8
-
HDMI version: HDMI 2.0
-
HDCP version: HDCP 2.2
-
HDMI resolution: up to 3840 * 2160/60Hz
-
Support Video Format: 8/10/12bit Deep color
-
Support Audio Format: DTS-HD/Dolby-trueHD/DTS/Dolby-AC3/DSD
-
Max Bandwidth: 600MHz
-
Max Baud Rate: 6Gbps
-
Input Cable Distance: (1080p Resolution) ≤8m, (4K Resolution)≤8m AWG26 HDMI Standard Cable
-
Output Cable Distance: (1080p Resolution) ≤8m, (4K Resolution)≤8m AWG26 HDMI Standard Cable
-
Max working current: 1A / 1.4A / 2A
-
Power adapter format: input AC (50Hz, 60Hz) 100V-240V; output: DC5V/2A
-
Operating Temperature range: (-15 to +55℃)
-
Dimension (L x W x H): 154x60x24(mm) / 211x78x27(mm) / 310x90x24(mm)
-
Weight: 335g / 504g / 864g
